Item	Self-Suspending Proppant
Product Code	JSZZ-I (0.85-0.425mm）	JSZZ-II（0.600-0.300mm）	JSZZ-III（0.425-0.212mm）
Appearance	Solid Particles
Complete Suspension Time (min)	≤3
Static Suspended Sand Stabilization Time (90°C, min)	≥30
base Fluid Apparent Viscosity (mPa.s)	≥50
Viscosity of base Fluid after Gel Breaking (mPa.s)	≤5
Surface Tension of base Fluid after Gel Breaking (mN/m)	≤50
Interfacial Tension after base Fluid Breaks Gel (mN/m)	≥90
Residue Discharge (%)	≤3
Quality Assurance Period	12 Months

Self-suspending proppant is a new type of proppant that organically combines proppant for fracturing with additives such as thickener through special technology. During fracturing construction, the self-suspending proppant and water are mixed in the sand mixer, and the self-suspending proppant particles can quickly build a stable suspended fracturing fluid system with the network interconnection structure formed therebetween. It only takes a few minutes to complete the liquid preparation-crosslinking-sand mixing link in traditional fracturing construction. It greatly saves manpower, equipment, and raw materials, making fracturing simpler, safer, energy-saving, and environmentally friendly.

Storage and transportation conditions

1. The self-suspending proppant should be stored in a cool and ventilated place, and should be kept away from heat and fire sources.

2.The self-suspending proppant should be protected from impact during transportation. It is strictly forbidden to mix with food for transportation.

Self-Suspending Proppant
